Fork Light Barrier - OGU 30/31-0 P2K-IBS

We’re known for our depth of knowledge. If you’re looking for a new supplier of sensors for factory automation, contact us today.

Operating principle	Optical
Transmitter light source	LED
Light color	Infrared
Fork opening	30 mm
Service voltage	10 … 35 V DC
No-load current (max.)	20 mA
Switching output	pnp, 200 mA, NO
Housing material	Aluminum
Ambient temperature during operation	-10 … +60 °C
Connection	Connector, M12, 4-pin
